| Model No | HTC12-500 |
| AC Input Specification | 1NAC 220V±10% 50/60Hz |
| Output Voltage Range | DC 0-12V |
| Output Current Range | DC 0-500A |
| Output Power Range | 6000W |
| Power Supply Stability Rate | 0.3%+10mV |
| Load Stabilization | less than or equal to 0.3%+30mV |
| Ripples and Noises | less than or equal to 1%+10mVrms |
| Voltage Display Accuracy | 4-digit display accuracy: ± 1% + 1 word (10% - 100% rated value) Display format 0.00V-99.99V 0-0V-999.9V |
| Current Display Accuracy | 4-digit display accuracy: ± 1% + 1 word (10% - 100% rated value) Display format 0.00A-99.99A 0-0A-999.9A |
| Insulation Resistance | Input output: ≥ 20m Ω Input housing: ≥ 20m Ω Output housing: ≥ 80m Ω |
| Insulation Strength | Input housing: ac1500v, 10mA, 1min Output housing: ac1500v, 10mA, 1min |
| O.V.P | Built in o.v.p protection, protection value is + 5% of rated value |
| O.C.P | Built in o.t.p protection, protection value is 85 ℃± 5% (radiator temperature) |
| Voltage Setting | 10-turn precision potentiometer |
| Current Setting | 10-turn precision potentiometer |
| Output Polarity | Output Positive(+) negative(-) Can be grounded at will |
| Work Conditions | Temperature -10℃-40℃, Humidity 10%-85%RH |
| Storage Environment | Temperature -20℃-70℃, Humidity 10%-90%RH |
| Product Size | 483*465*132mm |
| Heat Dissipation Mode | Forced ventilation and heat dissipation |
